BILD 800 walk-in wine rooms come with CellarPro cooling units, all-wood Universal racking, locks, and lights. The BILD Series Cabinets are packed and shipped flat, and offer tremendous value and savings with many of the same features as the more expensive Le Cache wine cabinets.
Must select venting option (exhaust) before adding to cart.
This item is oversized and does not qualify for free Economy Ground shipping.
$7,295.00
Hot Air Exhaust (MUST SELECT):
Color (MUST SELECT):
NOW WITH THE MOST ADVANCED AND QUIETEST COOLING UNITS FROM CELLARPRO!
BILD 800 walk-in wine rooms come with supercharged CellarPro 1800XTS-ECX cooling units, all-wood Universal racking, double-pane tinted glass windows, locks, and lights. Our BILD Series are packed and shipped flat, and offer tremendous value and savings with many of the same features as our more expensive Le Cache wine cabinets.
Total Capacity: 796+ bottles
Size: 83w x 50d x 83h (in)
Flat Rate Shipping. Remote locations or unique delivery requirements may result in additional shipping rates.
Build-it-yourself wine storage solutions made by Le Cache, BILD cabinets offer many of the same features as our other models—but for a fraction of the price.
CellarPro cooling units, included with BILD cabinets for no additional charge, maintain ideal, consistent temperature and humidity conditions for aging wine. Double-paned glass windows and high-density foam insulation shield your collection from heat and UV rays.
Exterior surfaces are finished with durable melamine, and fixed interior wood racks provide stable storage for bottles.
|
|
| Capacity: | 800 bottles |
|---|---|
| Size: | 83" W x 50" D x 83" H |
| Weight: | 1245 lbs |
| Power/Rating: | 115V AC / 60 Hz |
| RUNNING / STARTUP AMPS (COMPRESSOR): | CellarPro 1800XTS-ECX: 3.6 Amps / 22.2 Amps |
Ventilation requirements: The cooling unit can be top vented or rear vented, as follows:
Top venting means that the cooling unit’s intake and exhaust will occur at the top of the wine room (centered on either the left or the right wall). Top venting allows the wine room to be 2-3 inches away from adjacent walls, and requires 6 inches of clearance atop the wine room
Rear venting means that the cooling unit’s intake and exhaust will occur on the left or right wall of the wine room, and requires 4-6 inches of clearance behind the cooling unit.
In both configurations, ample clearance above or behind the cooling unit is necessary for proper air circulation, and the location must be sufficiently large for the hot air generated by the cooling unit to dissipate.
POWER REQUIREMENT:
The power cord extends 6 1/2 feet from the rear of the cabinet. If an extension cord is used, it should be 14-gauge wire or thicker, grounded, and as short as possible.
The cooling unit plugs into a standard grounded wall outlet. We recommend adding a surge protector, rated at 15 amps or more (for example, click here), to protect the cooling unit from power surges.
The outlet must be on a dedicated circuit. The components of the cooling unit draw 3 amps, and the electric outlet on the side of the cooling unit also is rated for 3 amps. The cooling unit should not, under any circumstances, share a circuit with another motor or compressor-based appliance, like a wine cooler, fridge, air conditioner, or garage opener.
FLOOR SURFACE:
The floor where you'll be placing the cabinet must be completely flat. Because of the significant weight of your wine cabinet, it is important that you consider the weight load factor of the floor as compared to the weight of the cabinet.
WEIGHT LOAD FACTOR:
After loading your wine cabinet with wine bottles, it will be extremely heavy. When selecting a location for your cabinet, make sure that the floor underneath is strong enough to support the weight of the cabinet (1195 lbs) plus the weight of the bottles (approx. 2400 lbs. assuming 800 bottles).
TEMPERATURE REQUIREMENTS:
CellarPro cooling units are designed to handle temperatures ranging from 50 to 95F.
VENTILATION REQUIREMENTS:
The cooling unit generates hot air that must be exhausted in such a way that it won't be recirculated by the cooling unit. If the hot air cannot be dissipated or channeled properly, and the cooling unit is forced to recycle its own hot air, the cooling unit will be unable to maintain cold temperatures inside the wine cabinet and/or will overheat and/or will run all the time.
The cooling unit can be installed to be top venting or rear venting.
If the cooling unit will be top venting, then the cooling unit will need at least 6 inches of clearance above the cabinet and 2-3 inches of clearance away from adjacent walls.
If the cooling unit will be rear venting, then the cooling unit will need 4-6 inches of clearance behind the cooling unit away from the adjacent wall.
ASSEMBLY REQUIRED:
BILD wine rooms and cabinets require assembly. All assembly hardware is included with your purchase.
Warranty: 1 Year (Cabinet) / 5 Years (Cooling Unit)
Optional Extended Warranty Available
Owners Manual: Click Here
Spec Sheet: Click Here
